3/4"公英制六角气动套筒
型号规格D1D2LPCS(六角符号）（mm）(mm)(mm)纸箱图片EF51007011730.14450100EF51007021831.44450100EF51007031932.64450100EF51007042033.84450100EF5
详情介绍
| 型号 | 规格 | D1 | D2 | L | PCS |
| (六角符号） | （mm） | (mm) | (mm) | 纸箱图片 | |
| EF5100701 | 17 | 30.1 | 44 | 50 | 100 |
| EF5100702 | 18 | 31.4 | 44 | 50 | 100 |
| EF5100703 | 19 | 32.6 | 44 | 50 | 100 |
| EF5100704 | 20 | 33.8 | 44 | 50 | 100 |
| EF5100705 | 21 | 35.1 | 44 | 50 | 100 |
| EF5100706 | 22 | 36.6 | 44 | 50 | 100 |
| EF5100707 | 23 | 37.6 | 44 | 50 | 100 |
| EF5100708 | 24 | 38.9 | 44 | 50 | 100 |
| EF5100709 | 25 | 40.1 | 44 | 50 | 100 |
| EF5100710 | 26 | 41.3 | 44 | 50 | 100 |
| EF5100711 | 27 | 42.6 | 44 | 53 | 100 |
| EF5100712 | 28 | 44 | 44 | 53 | 100 |
| EF5100713 | 29 | 45.1 | 44 | 53 | 100 |
| EF5100714 | 30 | 46.4 | 44 | 53 | 100 |
| EF5100715 | 31 | 47.6 | 44 | 53 | 100 |
| EF5100716 | 32 | 48.9 | 44 | 56 | 100 |
| EF5100717 | 33 | 50.6 | 44 | 56 | 100 |
| EF5100718 | 34 | 51.4 | 44 | 56 | 100 |
| EF5100719 | 35 | 52.7 | 44 | 56 | 100 |
| EF5100720 | 36 | 53.9 | 44 | 56 | 100 |
| EF5100721 | 37 | 55.2 | 44 | 57 | 100 |
| EF5100722 | 38 | 56.4 | 44 | 57 | 100 |
| EF5100723 | 39 | 57.7 | 44 | 57 | 100 |
| EF5100724 | 40 | 58.9 | 44 | 57 | 100 |
| EF5100725 | 41 | 60.1 | 44 | 57 | 80 |
| EF5100726 | 42 | 61.4 | 44 | 57 | 80 |
| EF5100727 | 43 | 62.7 | 44 | 62 | 80 |
| EF5100728 | 44 | 64 | 44 | 62 | 80 |
| EF5100729 | 45 | 65.2 | 44 | 62 | 80 |
| EF5100730 | 46 | 66.4 | 44 | 62 | 80 |
| EF5100731 | 47 | 67.6 | 44 | 67 | 80 |
| EF5100732 | 51 | 72.8 | 54 | 72 | 75 |
| EF5100733 | 52 | 73.9 | 54 | 72 | 75 |
| EF5100734 | 53 | 75.1 | 54 | 72 | 75 |
| EF5100735 | 54 | 76.4 | 54 | 72 | 75 |
| EF5100736 | 55 | 77.7 | 54 | 74 | 75 |
| EF5100737 | 56 | 79 | 54 | 74 | 75 |
| EF5100738 | 57 | 80.2 | 54 | 74 | 70 |
| EF5100739 | 58 | 81.5 | 54 | 75 | 70 |
| EF5100740 | 59 | 82.7 | 54 | 75 | 70 |
| EF5100741 | 60 | 84.1 | 54 | 75 | 70 |
| EF5100742 | 63 | 87.6 | 54 | 75 | 60 |
| EF5100743 | 65 | 90.2 | 54 | 78 | 60 |
| EF5100744 | 67 | 92.7 | 54 | 80 | 60 |
| EF5100745 | 70 | 96.4 | 54 | 83 | 60 |
| 型号 | 规格 | D1 | D2 | L | PCS |
| (六角符号） | （mm） | (mm) | (mm) | 纸箱图片 | |
| EF5100746 | 11/16" | 30.6 | 44 | 50 | 100 |
| EF5100747 | 3/4" | 32.6 | 44 | 50 | 100 |
| EF5100748 | 13/16" | 34.7 | 44 | 50 | 100 |
| EF5100749 | 7/8" | 36.6 | 44 | 50 | 100 |
| EF5100750 | 15/16" | 38.9 | 44 | 50 | 100 |
| EF5100751 | 1" | 40.7 | 44 | 50 | 100 |
| EF5100752 | 1-1/16" | 42.6 | 44 | 53 | 100 |
| EF5100753 | 1-1/8" | 44.5 | 44 | 53 | 100 |
| EF5100754 | 1-3/16" | 46.4 | 44 | 53 | 100 |
| EF5100755 | 1-1/4" | 48.9 | 44 | 56 | 100 |
| EF5100756 | 1-5/16" | 50.6 | 44 | 56 | 100 |
| EF5100757 | 1-3/8" | 52.7 | 44 | 56 | 100 |
| EF5100758 | 1-7/16" | 54.6 | 44 | 56 | 100 |
| EF5100759 | 1-1/2" | 56.4 | 44 | 57 | 100 |
| EF5100760 | 1-9/16" | 58.9 | 44 | 57 | 100 |
| EF5100761 | 1-5/8" | 60.1 | 44 | 57 | 100 |
| EF5100762 | 1-11/16" | 62.7 | 44 | 62 | 80 |
| EF5100763 | 1-3/4" | 64.5 | 44 | 62 | 80 |
| EF5100764 | 1-13/16" | 66.4 | 44 | 62 | 80 |
| EF5100765 | 1-7/8" | 68.8 | 44 | 67 | 80 |
| EF5100766 | 1-15/16" | 70.2 | 44 | 69 | 80 |
| EF5100767 | 2" | 72.8 | 54 | 72 | 70 |
| EF5100768 | 2-1/16" | 74.4 | 54 | 72 | 70 |
| EF5100769 | 1-1/8" | 76.4 | 54 | 72 | 70 |
| EF5100770 | 2-3/16" | 78.4 | 54 | 74 | 70 |
| EF5100771 | 2-1/4" | 80.2 | 54 | 74 | 70 |
| EF5100772 | 2-5/16" | 82.7 | 54 | 75 | 70 |
| EF5100773 | 2-3/8" | 84.1 | 54 | 75 | 70 |
| EF5100774 | 2-1/2" | 88.2 | 54 | 75 | 60 |
| EF5100775 | 2-5/8" | 92.3 | 54 | 80 | 60 |
| EF5100776 | 2-3/4" | 96.4 | 54 | 83 | 60 |
